Robotics Controllers Multipoint Digital I/O & 24Ch A/D & D/A (Commercial and Military)
Complex Waveform Generators (Commercial and Military)
16/24 Channel Electric Fence Detection and System Controller
Fast Prototyping and Concept Proofing (Lake/Ocean bottom Silt Level Detection)
Cellulose Ethanol Processing and Co-Generation
Hydroponic Lighting and Robotics
Developed Products
Adiabatic Reactor - developed and constructed in 1992, a high energy toroidal static magnetic field bubble and spherical dynamic magnetic field generator with laser couplings. This type of system is used in two areas; the relational effects produced through experimentation in the generation of BEC's and alternatively “close-to” ground state mixing of materials to produce altered physical structures and molecular linkages. Developed with the support of private companies and the National Research Council of Canada. Vortex owns intellectual property and technology rights. Developed in 1992. In use. (link to similar technology by others)
EPR Solution based, orthoganol information communcation system - operating at classical levels using a combination of very specific field effects to control local space and to potentially emulate a statistically probable quantum level functions (ER Bridge, etc). Prototypes are still under analysis. Developed with the support of the NRC, Universities and private companies. Vortex owns intellectual property and technology rights and has one non-exclusive license holder, Developed in 1994. In use.(link to other experiments)
Laser Interferometer - an attempt to measure high and low frequency gravity wavefunction effects at a distance. Internal project. Vortex owns intellectual property and technology rights.
Optical (Laser) Burst Transmitters -(secure communications) as would be used in line of sight applications and High Energy Security applications. Developed with Military support, in use. Vortex owns intellectual property and technology rights.
Programmable Logic Controllers. Internal projects supported by private companies. Vortex owns intellectual property and technology rights.
AC ASK and DPSK Power Line Modem and Communication Systems - (LAN's and WAN's) to provide an apparent wireless solution for interoffice computer and voice communications in a broadband environment over the existing AC power lines. This type of system may be used in local DC based systems as well for the purposes of enabling distributed processing in complex machines and vehicles. Internal project, developed in 1989 . It is also known as “Smart Meter” technology.
Neurological Entrainment Systems - a system primarily used to modify brain wave patterns to cause alteration in thinking processes and concentration levels by remotely producing synchronization between left and right hemispheres. Internal project. Vortex owns intellectual property and technology rights.
FerroPolymers - for the purpose of altering the visibility of objects to radar systems, generating uniform heating surfaces and to act as thermal entropy based energy collection and conversion systems similar to a combination of piezo-electric, resistive and thermocouple type devices. Internal project. Vortex owns intellectual property and technology rights.
Underwater Silt Depth and Depth Measurement Transducers - for high accuracy material deposit recovery, waste management and remediation as would be applied by the Great Lakes 2000 project. Internal project generated to support the Ministry of the Environment application for same. Vortex owns intellectual property and technology rights.
Underwater Telemetry and Signal Conversion Systems - for Underwater ROV robotics controllers and applications. Developed with the support of private companies. Sold and in use. Vortex owns intellectual property and technology rights.
Security Systems - Perimeter, Lethal and Non-Lethal - High Voltage/High Energy electric fences and barrier detection systems, 4kv to 48kv, up to 25kva. These types of systems are military application only. Developed with Military support. Vortex owns intellectual property and technology rights.
Security Systems - High Energy Lasers and Auto-Thermal Compensation CryoSinks - 850 to1500nm, 10kw to 3 terrawatts, 0.1 mm to 50 mm beam. Military applications only and can be plasma coupled burst or nuclear source particle beam system using ring style/tubular laser carriers. Array semiconductor applications only. EMP systems were also examined using SLW technology. Developed with Military support. Vortex owns intellectual property and technology rights.
Security Systems - VL and NIR Laser Targeting for Handheld Weapons.- Low energy 10 mw to 100 mw upper or lower barrel mount targeting lasers. Long range IR systems require scopes with IR window. Developed with Military support.
Security Systems - Telemetry and Target Tracking - using thermal imaging and standard camera's that have information converted to planar bit images for the purposes of image analysis and identification. Developed with Military support.
Security Systems - Secure Communications and Encryption - using modified RSA type and 'Key Seeded RSA Real Time Mutation Algorithm' (KSRM). Generally for military or financial sector applications requiring literally unbreakable security protocols. Developed with Military support.
Security Systems - Access Control and Site/Perimeter Monitoring - using standard protocols. Acoustic cables systems are used for determining distance to targets, target speed and target mass determination where possible. Developed with Military support.
Security Systems - PTZ Camera Controllers - using Intel 80C196 products. Developed with Military support. Vortex owns intellectual property and technology rights.
Security Systems - AI Based, Environmental Learning - to provide auto-startup after brownouts and system shutdowns. AI feature also accommodate auto-reconfiguration of the system as it grows in size and/or complexity. This type of system is used generally in complex fence type military security applications involving Border or Military base monitoring as it provides auto-scaling and reduces tech intervention. Developed with Military support. Vortex owns intellectual property and technology rights.
Security Systems - Mimic and Status Indication - as applied to Military, Key Point and standard installations. Developed with Military support. Vortex owns intellectual property and technology rights.
Security Systems - Vehicle ID and Tracking, UHF and microwave 'ticklers' using the Doppler Effect to measure received wave angle to provide direction, distance and speed. Transmitter uses a constant Output Amplitude Modulator to insure that the signal is consistent. Onboard tracking system takes into account user inputed changes in weather patterns to compensate for signal strength. Developed with the support of private companies. Vortex owns intellectual property and technology rights.
High Voltage Variable Power Supplies - 10kv to 500kv for encapsulated plasma experimentation. Developed with the support of private companies. In use. Vortex owns intellectual property and technology rights.
DC - DC Converters and Inverters - (transformerless) for use in vehicles and Uninterruptable Power Supplies (UPS). Developed with the support of private companies. In use. Vortex owns intellectual property and technology rights.
Variable and Locked Frequency Inverters and Power Factor Controllers - to 6 megawatts (VFI's, VFD's, LFI's, PFC’s and UPS's). Developed with the support of private companies. In use. Vortex owns intellectual property and technology rights.
Encryption Systems -Consumer type Random Key Seeding Algorithm, 64/128 bit advanced RSA format only. Developed with the support of private companies. Vortex owns intellectual property and technology rights.
Data Acquisition Systems - Temperature, Speed, Acceleration, Pressure, Flow Rate. Developed with the support of private companies. In use. Vortex owns intellectual property and technology rights.
Bandpass and Multiplexer Systems - Voice and Data for Broadband Radio Communications Systems. Developed with Military support. Vortex owns intellectual property and technology rights.
Reflected Light Frequency Measurement System - as used to measure the frequency of colour for paint matching purposes. Internal project. Vortex owns intellectual property and technology rights.
Hydrogen Generator - Runs on 5vdc and produces 4 to 12 liters per minute (so far).
Ethanol Web Process System - Would fit inside a standard shipping container and produce up to one megawatt of “green” sustainable electricity using waste cellulose as fuel. Vortex owns intellectual property and technology rights.
Vortex owns intellectual property and technology rights for the above specified devices in the form as developed by Vortex Research Inc.. Additional Copyrights (c) may apply.
